Field of view: 360° horizontal and with tripod mount also vertical
Dimensions (H x W x D):6.5 mm x 8.4 mm x 8.4 mm
Weight: 365 g

Rotation angle definition: 0.225°
Pitch tolerance (in Manual mode only): ± 0.075°

Supported power supply: 5V DC, 100-240V AC
Internal batteries 2x: Li-Ion 1820mAh 3.7V
Power plug: 2A Europlug power supply (included),
USB type C – USB Type A cable (included)
Durability: more than 120 continuous measurements
Durability: more than 7 days standby time

Processor: M1-nRF52 family General-purpose multi protocol SoC built around the Arm® Cortex™-M4 CPU with floating point unit running at 64 MHz.
Data storage capacity: 2Mb internal short-time storage + storage in device Application + Cloud service (not included)
Communication and Data Transfer: Bluetooth Low Energy 5.2 with high-speed 2 Mbps feature.
Inertial measurement system: two 9axis small low power, low noise absolute orientation units

Operating temperature: -10°C / + 35°C – 14°F / + 95°F
Storage temperature: -25°C / + 60°C – -13°F / +140°F
Humidity: 95% non-condensing

Files exported in .DXF multilayer

iOS equal to or greater than 13
Android equal to or greater than 9

Mobile device (not included): via “TheMeter” app for Android (available on Android store) and iOS (available on Apple store) for Smart Phones, Tablets, iPhones and iPads.

Field of view: 360° horizontal and with tripod mount also vertical
Dimensions (H x W x D):6.3 mm x 8.4 mm x 8.4 mm
Weight: 335 g

Definition of angle of rotation: 0.113°
Pitch tolerance (in Manual mode only): ± 0.038°

Supported power supply: 5V DC, 100-240V AC
Internal batteries 2x: Li-Ion 1820mAh 3.7V
Power plug: 2A Europlug power supply (included), USB type C – USB
Type A cable (included)
Durability: more than 400 continuous surveys
Duration: days 35

Dual processor: PIC32CM by Microchip Technology in ARM Cortex-M4F architecture at 48 MHz
Data storage capacity: 2Mb internal short-time storage + storage in device Application + Cloud service (not included)
Communication and Data Transfer: Bluetooth Low Energy 5.2 with high-speed 2 Mbps feature
Inertial measurement system: new Imu by Bosch Sensortec with accelerometer with sensitivity up to ±2g: 16384 LSB/g, gyroscope with sensitivity up to ±125°/s: 262.4 LSB/°/s, magnetometer with sensitivity up to ±125°/s

Operating temperature: -10°C / + 40°C – 14°F / + 104°F
Storage temperature: -25°C / + 60°C – -13°F / +140°F
Humidity: 95% non-condensing

Exported files in customizable multilayer .DXF

iOS equal to or greater than 13
Android equal to or greater than 9

Mobile device (not included): via “TheMeter” app for Android (available on Android store) and iOS (available on Apple store) for Smart Phones, Tablets, iPhones and iPads.

Field of view: 360° horizontal and with tripod mount also vertical
Dimensions (H x W x D):6.3 mm x 8.4 mm x 8.4 mm
Weight: 335 g

Rotation angle definition: 0.225°
Pitch tolerance (in Manual mode only): ± 0.075°

Supported power supply: 5V DC, 100-240V AC
Internal batteries 2x: Li-Ion 1820mAh 3.7V
Power plug: 2A Europlug power supply (included), USB type C – USB
Type A cable (included)
Durability: more than 400 continuous surveys
Duration: days 35

Doppio processore: PIC32CM di Microchip Technology in architettura ARM Cortex-M4F a 48 MHz
Data storage capacity: 2Mb internal short-time storage + storage in device Application + Cloud service (not included)
Communication and Data Transfer: Bluetooth Low Energy 5.2 with high-speed 2 Mbps feature
Inertial measurement system: nuova Imu by Bosch Sensortec con accelerometro con sensibilità fino a ±2g: 16384 LSB/g, giroscopio con sensibilità fino a ±125°/s: 262.4 LSB/°/s, magnetometro con sensibilità fino a ±125°/s

Operating temperature: -10°C / + 40°C – 14°F / + 104°F
Storage temperature: -25°C / + 60°C – -13°F / +140°F
Humidity: 95% non-condensing

Exported files in customizable multilayer .DXF

iOS equal to or greater than 13
Android equal to or greater than 9

Mobile device (not included): via “TheMeter” app for Android (available on Android store) and iOS (available on Apple store) for Smart Phones, Tablets, iPhones and iPads.

Field of view: 360° horizontal and with tripod mount also vertical
Dimensions (H x W x D):6.3 mm x 8.4 mm x 8.4 mm
Weight: 340 g

Definition of angle of rotation: 0.113°
Pitch tolerance (in Manual mode only): ± 0.038°

Supported power supply: 5V DC, 100-240V AC
Internal batteries 2x: Li-Ion 1820mAh 3.7V
Power plug: 2A Europlug power supply (included), USB type C – USB
Type A cable (included)
Durability: more than 400 continuous measurements
Duration: 15 days

Processor: M1-nRF52 family General-purpose multi protocol SoC built around the Arm® Cortex™-M4 CPU with floating point unit running at 64 MHz.
Data storage capacity: 2Mb internal short-time storage + storage in device Application + Cloud service (not included)
Communication and Data Transfer: Bluetooth Low Energy 5.2 with high-speed 2 Mbps feature.
Inertial measurement system: two 9axis small low power, low noise absolute orientation units

Operating temperature: -10°C / + 40°C – 14°F / + 104°F
Storage temperature: -25°C / + 60°C – -13°F / +140°F
Humidity: 95% non-condensing

Exported files in customizable multilayer .DXF

iOS equal to or greater than 13
Android equal to or greater than 9

Mobile device (not included): via “TheMeter” app for Android (available on Android store) and iOS (available on Apple store) for Smart Phones, Tablets, iPhones and iPads.

Field of view: 360° horizontal and with tripod mount also vertical
Dimensions (H x W x D):6.3 mm x 8.4 mm x 8.4 mm
Weight: 340 g

Rotation angle definition: 0.225°
Pitch tolerance (in Manual mode only): ± 0.075°

Supported power supply: 5V DC, 100-240V AC
Internal batteries 2x: Li-Ion 1820mAh 3.7V
Power plug: 2A Europlug power supply (included), USB type C – USB
Type A cable (included)
Durability: more than 400 continuous measurements
Duration: 15 days

Processor: M1-nRF52 family General-purpose multi protocol SoC built around the Arm® Cortex™-M4 CPU with floating point unit running at 64 MHz.
Data storage capacity: 2Mb internal short-time storage + storage in device Application + Cloud service (not included)
Communication and Data Transfer: Bluetooth Low Energy 5.2 with high-speed 2 Mbps feature.
Inertial measurement system: two 9axis small low power, low noise absolute orientation units

Operating temperature: -10°C / + 40°C – 14°F / + 104°F
Storage temperature: -25°C / + 60°C – -13°F / +140°F
Humidity: 95% non-condensing

Exported files in customizable multilayer .DXF

iOS equal to or greater than 13
Android equal to or greater than 9

Mobile device (not included): via “TheMeter” app for Android (available on Android store) and iOS (available on Apple store) for Smart Phones, Tablets, iPhones and iPads.

Field of view: 360° horizontal and with tripod mount also vertical
Dimensions (H x W x D):6.5 mm x 8.4 mm x 8.4 mm
Weight: 345 g

Rotation angle definition: 0.45°
Pitch tolerance (in Manual mode only): ± 0.15°

Supported power supply: 5V DC, 100-240V AC
Internal batteries 2x: Li-Ion 1820mAh 3.7V
Power plug: 2A Europlug power supply (included), USB type C – USB
Type A cable (included)
Durability: more than 60 continuous measurements
Durability: days standby 2

Processor: M1-nRF52 family General-purpose multi protocol SoC built around the Arm® Cortex™-M4 CPU with floating point unit running at 64 MHz.
Data storage capacity: 2Mb internal short-time storage + storage in device Application + Cloud service (not included)
Communication and Data Transfer: Bluetooth Low Energy 5.2 with high-speed 2 Mbps feature.
Inertial measurement system: two 9axis small low power, low noise absolute orientation units

Operating temperature: -10°C / + 35°C – 14°F / + 95°F
Storage temperature: -25°C / + 60°C – -13°F / +140°F
Humidity: 95% non-condensing

Files exported in .DXF multilayer

iOS equal to or greater than 13
Android equal to or greater than 9

Mobile device (not included): via “TheMeter” app for Android (available on Android store) and iOS (available on Apple store) for Smart Phones, Tablets, iPhones and iPads.
